0386-0101 - TurboTorch A-3 Extreme Air Acetylene Swirl Tip

Technical Overview of the TurboTorch A-3 Extreme Tip

The TurboTorch A-3 Extreme Air Acetylene Tip (SKU: 0386-0101) is a precision-engineered component designed for professional HVAC and plumbing applications. Utilizing proprietary Swirl Combustion Technology, this tip generates a high-velocity, high-temperature flame that maximizes heat transfer to the workpiece. This design allows for rapid heating of copper tubing, significantly reducing labor time compared to standard tips. The A-3 tip features a 3/16-inch (4.8 mm) flame opening and operates efficiently with a gas flow of 3.6 scfh at 14 PSI.

Engineered for versatility and durability, the A-3 tip is rated for soft soldering copper tubing ranging from 1/4 inch to 1 inch (6-25 mm) and silver brazing from 1/8 inch to 1/2 inch (3-13 mm). It is specifically designed to interface with TurboTorch G-4 and PLF-A5 handles via a quick-disconnect coupling mechanism, ensuring a secure and leak-proof seal. The integration of color-coded red O-rings provides immediate visual verification for acetylene gas compatibility, adhering to safety standards and preventing cross-connection with other fuel gases.

Maintenance and longevity are addressed through the inclusion of a removable orifice screw. This feature allows technicians to easily clean the internal passage or replace the orifice (Part No. OR-A3) if it becomes clogged or worn, thereby extending the service life of the tip assembly. The industrial-grade construction ensures resilience against the thermal and mechanical stresses common in field environments. This tip represents a standard in air-acetylene brazing efficiency, eliminating the need for oxygen cylinders while delivering performance suitable for light fabrication and repair tasks.
