The TurboTorch T-3 Replacement Tip (SKU: 0386-0151) represents a standard in manual air-fuel torch technology, specifically engineered for the professional HVAC technician, plumber, and light fabrication specialist. This component is part of the renowned TurboTorch T-Series, designed to interface seamlessly with standard manual torch handles. The core innovation within the T-3 tip is the proprietary Swirl Combustion Technology. Unlike standard flame tips that produce a feather flame, the Swirl Combustion design forces the air-fuel mixture into a high-velocity vortex. This results in a concentrated, high-heat zone that wraps around the workpiece, significantly improving heat transfer efficiency and reducing the time required to reach working temperatures for solder and braze alloys.
Thermodynamically, the T-3 tip is optimized for use with high-energy fuel gases, specifically Propane and MAP-Pro (propylene-based mixes). When operating on Propane at a delivery pressure of 24 psi, the tip consumes approximately 0.20 cubic feet per hour (cfh), providing a controlled heat output suitable for soft soldering copper tubing ranging from 1/4 inch to 1 inch in diameter. For applications requiring higher thermal flux, such as silver brazing or working on slightly larger diameter pipes, the use of MAP-Pro gas is recommended. At 42 psi, the flow rate increases to 0.25 cfh, extending the soft soldering capacity to 1-1/2 inches and enabling silver brazing on tubing from 1/4 inch to 1/2 inch. This dual-gas compatibility allows technicians to carry a single tip for a variety of field conditions.
Maintenance and longevity are critical in industrial environments. The T-3 tip features a removable orifice screw, a distinct advantage over crimped or sealed tip designs. In the event of a clog due to carbon buildup or debris ingress, the orifice can be easily extracted, cleaned, and reinstalled, restoring the tip to optimal performance without the need for total replacement. The physical construction involves high-quality brass and stainless steel components, ensuring resistance to thermal cycling and mechanical stress typical of job site usage. The tip measures approximately 1.9 inches in length with a 7/16-inch flame opening, providing a balance between accessibility in tight spaces and sufficient flame coverage.
| Additional Information |
|---|
| Brand:TurboTorch |
| Fuel Gas:Propane, MAPP |
| Item:Heating Tip |
| Packaging Description:1-per-each |
| Tip Size:7/16" |
| Tip Series:T-3 |
| Soft Solder Capacity (Propane):1/4" to 1" |
| Soft Solder Capacity (MAP Pro):1/4" to 1-1/2" |
| Silver Braze Capacity (Propane):1/8" to 1/2" |
| Silver Braze Capacity (MAP Pro):1/4" to 1/2" |
| Gas Flow (Propane):0.20 cfh @ 24 psi |
| Gas Flow (MAP Pro):0.25 cfh @ 42 psi |
