275961 - Miller BreatheAir 2-Person SAR Filtration Panel with 10ppm CO Alarm

Advanced Respiratory Protection for Industrial Environments

The Miller BreatheAir™ Panel (275961) is a high-performance, stationary filtration system designed to provide Grade-D breathing air for up to two operators simultaneously. Engineered for heavy-duty industrial applications, this wall-mounted unit is an essential component for facilities utilizing Supplied Air Respirators (SAR). By connecting to a standard shop air compressor, the BreatheAir panel filters out contaminants to ensure that workers are breathing safe, clean air, even in environments with high levels of welding fumes or particulate matter.

Three-Stage Filtration Technology

This system utilizes a robust three-stage filtration process to ensure maximum purity. The first stage effectively removes 95% of bulk liquids and particulates down to 5.0 microns. The second stage targets finer contaminants, eliminating 99.99% of fine oil mists and particulates down to 0.01 microns. Finally, the third stage utilizes activated carbon to remove organic vapors, odors, and tastes, significantly improving the breathing experience for the user. An automatic condensation drain is integrated into the system to continuously remove moisture, extending the life of the filter cartridges and reducing maintenance frequency.

Integrated Safety Monitoring

Safety is paramount with the BreatheAir system. It features an internal monitor that continuously tracks Carbon Monoxide (CO) levels in the supplied air. If CO levels exceed the safety threshold of 10 parts per million (ppm), the unit triggers both external warning lights and high-decibel audible alarms, allowing users to react immediately to hazardous conditions. The monitor is designed for efficiency, with a calibration process that takes less than two minutes, minimizing operator downtime while maintaining strict safety standards.

User-Friendly Maintenance

Miller has designed this panel to eliminate guesswork regarding maintenance. Each of the three filter cartridges is equipped with a change indicator that clearly notifies users when a replacement is needed. This feature ensures the unit is always performing at peak efficiency and prevents the usage of saturated filters. The quick-change filter process further reduces downtime, keeping your operations running smoothly. With a capacity of 49 CFM, this 2-person panel is a reliable solution for ensuring OSHA compliance and protecting worker health in manufacturing and fabrication settings.
