The Tweco Classic No. 4 MIG Gun (Part Number 1040-1902) is a semi-automatic, air-cooled welding gun engineered for high-performance industrial applications. Rated at 400 Amps at a 60% duty cycle using CO2 gas, this gun is designed to handle the rigors of structural steel fabrication, heavy equipment manufacturing, and shipbuilding. The assembly features a 12-foot cable, providing a practical balance between operator mobility and consistent wire feeding performance.
At the core of the Classic No. 4 is its heavy-duty construction. The cable utilizes a robust copper conductor that ensures efficient electrical conductivity and heat dissipation, reducing the operating temperature of the gun during prolonged use. The conductor tube is metal-jacketed, offering superior protection against impact and spatter compared to standard insulation. The rear connection is the widely adopted Tweco style, ensuring compatibility with a vast range of wire feeders and power sources equipped with Tweco adapters.
Maintenance and serviceability are key design philosophies of the Classic series. The gun features mechanical cable connections that allow for field repairs without the need for specialized crimping tools. Consumables are readily available and easy to replace, utilizing the standard Tweco 14 Series contact tips, 24 Series gas nozzles, and 54 Series gas diffusers. This specific configuration (1040-1902) comes ready to weld with a setup typically optimized for .035" to .045" solid wires, though it can accommodate wire diameters up to 5/64" (2.0 mm) with the appropriate liner and tip changes.
For procurement and MRO managers, the Tweco Classic No. 4 represents a low-risk, high-value investment. Its proven track record for longevity reduces the frequency of replacement, while the widespread availability of parts simplifies inventory management. It is an essential tool for any operation requiring reliable, high-amperage GMAW capabilities.
| Additional Information |
|---|
| ----- new values below ---- |
| Cooling Method:Air Cooled |
| Duty Cycle:60% at 400A |
| Connection Type:Tweco Style |
| Wire Diameter Capacity:Up to 5/64" (2.0 mm) |
| Conductor Type:Heavy-Duty Copper |
| Amps:400 |
| Brand:Tweco |
| Cable Length:12 ft |
| Process Type:MIG (GMAW) |
