The Lincoln Electric K3359-120ICW is a premium Magnum PRO Robotic 550 Welding Gun designed as a complete Ready-Pak solution for the Fanuc 120iCW robotic arm. This air-cooled, thru-arm welding gun is engineered to meet the rigorous demands of high-speed automated manufacturing environments. It integrates seamlessly with the robot's structure, protecting the cable assembly within the arm to minimize wear and interference during complex movements.
A defining characteristic of this system is its Single Tool Center Point (TCP) capability. This engineering feat allows operators to switch between 350A and 550A expendable parts without altering the robot's TCP. This versatility significantly reduces setup time and programming adjustments when changing between light and heavy-duty welding tasks. The gun utilizes Lincoln's renowned Magnum PRO consumables, known for their extended service life and consistent arc performance.
The K3359-120ICW features the innovative HexConnect™ Gun Bushing. Unlike traditional rotating connections that can suffer from micro-arcing and wear, the HexConnect design ensures full-face electrical contact. This results in superior conductivity and arc stability throughout the life of the gun. Additionally, this Ready-Pak includes a Wire Brake, a critical component for applications requiring touch sensing, ensuring the wire stops instantly for accurate part location.
Constructed with a robust cable system that exceeds industry standards, this robotic gun is built to withstand the repetitive torsion and flexing inherent in robotic welding. The extended reach mounting bracket further enhances the system's utility, allowing the torch to access hard-to-reach joints without compromising the robot's range of motion.
| Additional Information |
|---|
| Brand:Lincoln Electric |
| Amperage Class:550 A |
| Cooling Method:Air Cooled |
| Torch Type:Robotic Thru-Arm |
| Robot Compatibility:Fanuc 120iCW |
| Process Type:MIG, Flux-Cored |
| Included Features:Wire Brake |
| Consumable Series:Magnum PRO |
| Cable Type:Thru-Arm |
| Packaging Description:1 Per Ea |
