The Lincoln Electric Magnum® PRO 1520ID Air Blast One-Pak® (K3359-1520IDA) is a specialized robotic torch package engineered exclusively for the ABB® IRB 1520ID robot arm. Designed to meet the rigorous demands of high-volume automated manufacturing, this air-cooled torch system integrates seamlessly with the robot's hollow-wrist design, protecting cables from wear and snagging while maximizing the work envelope. The "One-Pak" configuration ensures you receive a complete, pre-configured system ready for immediate installation, streamlining the integration process for systems integrators and maintenance departments alike.
A defining feature of this model is the Air Blast capability. This integrated pneumatic function delivers a high-pressure burst of air through the nozzle, effectively clearing spatter and debris during the reaming cycle. This automated cleaning feature is crucial for maintaining weld quality and prolonging the lifespan of consumables in continuous production environments. By reducing the frequency of manual nozzle cleaning, the Air Blast feature directly contributes to higher overall equipment effectiveness (OEE).
The Magnum PRO 1520ID is built on a foundation of operational efficiency. It utilizes Lincoln Electric's Single Tool Center Point (TCP) design, which allows operators to interchange between 350A and 550A expendables without altering the robot's programmed TCP. This versatility enables rapid adaptation to changing welding parameters without the downtime associated with reprogramming trajectories. Furthermore, the system features the patent-pending HexConnect™ Gun Bushing. Unlike traditional rotating connections that rely on single-line contact, HexConnect ensures full-face electrical contact, significantly improving conductivity and eliminating the micro-arcing that leads to premature component failure.
Durability is paramount in robotic applications, and the Magnum PRO cables are engineered to surpass industry standards. Testing confirms these cables withstand over twice the repetitive torsion and flexing of standard cables, ensuring reliable performance shift after shift. Combined with the extended reach mounting bracket and simplified expendable parts selection, the K3359-1520IDA is the premier choice for fabricators utilizing ABB robotics.
| Additional Information |
|---|
| Brand:Lincoln Electric |
| Cooling Method:Air Cooled |
| Process:MIG (GMAW), Robotic Welding |
| Packaging Description:1 Per Ea |
| Torch Type:Robotic Air-Cooled |
| Compatibility:ABB IRB 1520ID Arms |
| Features:Air Blast, Single TCP, HexConnect |
| Amperage Class:350A, 550A |
