The Miller Spoolmatic 30A Spool Gun (SKU: 130831) is engineered for professional welders who demand reliability and precision in aluminum fabrication. Designed to operate with industrial power sources like the Millermatic 252, this spool gun eliminates the feeding issues often associated with pushing soft aluminum wire through standard MIG torches. With a robust 200 Amp output at 100% duty cycle, the Spoolmatic 30A is built to withstand continuous use in heavy manufacturing, shipbuilding, and trailer fabrication environments.
One of the standout features of this model is the 30-foot (9.1 meter) cable assembly. This extended length provides operators with the freedom to move around large workpieces, such as truck bodies or boat hulls, without the need to constantly reposition the welding machine. To further enhance operator comfort, the integrated spool canister is designed to rotate 180 degrees. This flexibility reduces wrist strain and allows the gun to access hard-to-reach welds with ease.
Efficiency is key in industrial settings, and the Spoolmatic 30A delivers with on-gun controls. The wire feed speed adjustment is conveniently located on the handle, allowing the welder to fine-tune parameters without returning to the power source. The two-stage trigger includes a built-in gas valve that initiates gas preflow before the arc strikes, ensuring a clean start and eliminating the need to purge long gas lines. Maintenance is streamlined with reversible drive rolls and a quick-change, single-turn contact tip system, keeping downtime to an absolute minimum.
While optimized for aluminum wire ranging from .030 to 1/16 inch, the Spoolmatic 30A is also capable of feeding hard wires up to .045 inch, making it a versatile tool for various soft alloy applications. The barrel is compatible with Roughneck and Bernard Centerfire consumables, ensuring that replacement parts are readily available and easy to install.
| Additional Information |
|---|
| Brand:Miller |
| Amperage:200 |
| Length:30 ft |
| Wire Size:0.030" - 1/16" |
| Fits Which Model:Millermatic 252, 250, 250MP |
| Wire Type:Aluminum |
| Process Type:MIG (GMAW), Pulsed MIG (GMAW-P) |
| Cable Length:30 ft |
| Duty Cycle:100% @ 200A |
| Wire Speed Range:70 - 875 IPM |
| Spool Size Capacity:4 in (102 mm) |
| Net Weight:14 lb (6.4 kg) |
| Packaging Description:1 of each |
| Front End:Miller |
| Back End:Miller |
