The Thermal Dynamics 9-8226 Gouging Tip B is a specialized plasma consumable designed for use with the SL60 and SL100 1Torch systems. This package contains five (5) genuine OEM tips, ensuring consistent performance and compatibility with Thermal Dynamics Cutmaster series plasma cutters. The Tip B configuration is engineered for an amperage output range of 50 to 100 Amps, making it a versatile choice for medium to heavy-duty gouging applications.
This gouging tip is categorized as a "Nozzle" consumable within the 1Torch ecosystem. It is specifically rated for a "Deep/Narrow" gouge profile, which is achieved by maintaining a constant standoff distance and angling the torch to a lead angle of 35-45 degrees. The 9-8226 is compatible with a broad array of power sources, including the Cutmaster 52, 81, 82, 101, 102, 151, and 152. It functions by constricting the plasma arc to blow away molten metal, effectively removing welds or defects without severing the base material.
To install, the tip is secured within the torch head assembly of the SL60 or SL100 torch. It can be used in conjunction with the Shield Cup Body and either the Gouging Shield Cap or Shield Deflector. Alternatively, it fits the single-piece Shield Cup configuration. Proper installation is critical for maintaining the gas flow dynamics required for effective plasma gouging. Users should verify their machine's amperage settings fall within the 50-100A range to prevent premature wear of the tip orifice.
Manufactured from high-grade copper, these tips are designed to withstand the intense heat of the plasma arc. The precision-machined orifice ensures a stable arc column, which is essential for controlling the depth and width of the gouge. As a genuine Thermal Dynamics part, the 9-8226 meets strict quality control standards, offering reliable ignition and consistent metal removal rates for industrial MRO environments.
| Additional Information |
|---|
| Brand:Thermal Dynamics |
| Item:Nozzle Tip |
| Amperage:100 |
| Packaging Description:pack-of-5 |
| Product Type:Gouging Tip |
| Tip Size:Tip B |
| Amperage Range:50-100 A |
| Gouge Profile:Deep/Narrow |
| Compatible Torches:SL60, SL100 |
| Compatible Models:Cutmaster 52, Cutmaster 81, Cutmaster 82, Cutmaster 101, Cutmaster 102, Cutmaster 151, Cutmaster 152 |
