K3310-1 - Lincoln Electric Pivot Angle Magnetic Clamp 200lbs

Master Complex Angles with the Lincoln Electric Pivot Angle Magnetic Fixture

In the world of metal fabrication, precision and safety are paramount. The Lincoln Electric Pivot Angle Magnetic Fixture (K3310-1) is engineered to address the common challenges of positioning steel for tacking, welding, and assembly. Unlike standard fixed-angle magnets that limit you to 45 or 90 degrees, this innovative tool features pivoting arms that allow for a massive range of motion, covering angles from 22 degrees all the way to 270 degrees. This flexibility makes it an indispensable asset for custom fabrication shops where unique geometries are the norm rather than the exception.

One of the standout features of this fixture is its On/Off magnetic technology. Traditional magnets are always "live," making them difficult to position precisely and even harder to clean when they attract metal shavings and swarf. With the K3310-1, a simple half-turn of the control knob activates or deactivates the magnetic field. This means you can position the tool exactly where you need it without fighting the magnetic pull, turn it on to secure the workpiece, and then turn it off to wipe away debris instantly. This feature not only saves time but also enhances workplace safety by minimizing the need for your hands to be in close contact with heavy, sharp, or hot steel components.

Despite its compact and lightweight design, which allows it to fit into tight spaces, this tool packs a punch with a magnetic holding force of 200 lbs (90 kg). The axis magnets mounted on the pivot arms provide a work surface on each side, enabling you to secure the tool to a welding table or wall while simultaneously holding your workpiece. The multi-angle surface is designed with V-grooves, making it equally effective at gripping flat plate and round tubing. Whether you are lifting sheet steel or setting up a complex frame, the Lincoln Pivot Angle Magnetic Fixture streamlines your workflow and ensures accurate, repeatable results.
