K1654-6 - Lincoln Electric Statiflex 200-M Wall-Mounted Fume Extractor with MERV 16 Filter

Technical Overview of the Lincoln Electric Statiflex 200-M

The Lincoln Electric Statiflex 200-M (K1654-6) is a stationary, wall-mounted low vacuum system engineered for the extraction and filtration of welding fumes in light to medium-duty applications. Designed specifically for facilities with fixed workstations and limited floor space, this unit integrates seamlessly into industrial environments such as job shops, welding schools, and maintenance departments. The system is built around a robust 1 HP fan capable of delivering 735 CFM of airflow, ensuring effective capture of airborne particulates at the source when paired with an appropriate extraction arm.

At the core of the Statiflex 200-M is its high-efficiency filtration system. The unit comes equipped with a MERV 16 rated filter, which is essential for capturing fine weld fumes and maintaining a cleaner working environment. The filter features a 3-D pleated structure with a substantial surface area of 538 square feet (50 square meters). This generously sized filter capacity not only improves filtration efficiency but also significantly lowers operational costs by extending the lifespan of the filter cartridge. Additionally, the system includes an integrated spark arrestor that functions as a pre-filter, capturing larger particulates and reducing the risk of fire hazards within the filter housing.

The mechanical configuration of the K1654-6 is designed for versatility and durability. The wall-mount bracket allows for secure installation above the work area, keeping the floor clear for equipment and operators. The unit includes a connection hose (8-inch diameter, 4-foot length) and necessary clamps for immediate setup of the base system. It is compatible with Lincoln Electric's flexible extraction arms (available in 10-foot or 13-foot lengths, sold separately), allowing users to tailor the reach of the system to their specific shop layout. The Statiflex 200-M represents a reliable, high-performance solution for stationary fume control.
