K4468-5 - Lincoln Prism Wall Mount Mechanized Cleaning One-Pak with 10ft Arm

Advanced Stationary Fume Extraction Technology

The Lincoln Electric Prism® Wall Mount Mechanized Cleaning One-Pak® (K4468-5) represents a sophisticated solution for stationary welding fume management. Designed specifically for light to medium duty applications in job shops, welding schools, and maintenance departments, this system leverages low vacuum, high volume airflow to effectively capture particulates at the source. The unit is anchored by the Prism 2400 Fan, a 1 HP motor capable of delivering 735 CFM of airflow, ensuring that fumes are drawn away from the operator's breathing zone before they can disperse into the facility.

High-Efficiency MERV 16 Filtration

At the core of the Prism system is its advanced filtration capability. The unit utilizes a MERV 16 Nano filter set (KP2752-16), which is engineered to capture 95% or more of particles in the 0.3 to 1.0 micron range. This level of filtration is critical for trapping the fine metallic oxides found in welding fumes. To protect the primary filters and extend their service life, the system includes an integrated spark arrestor and a pre-filter (KP1673-6) that captures larger particulates and mitigates fire risks by deadening sparks before they reach the filter media.

Mechanized Cleaning & Automation

Operational efficiency is maximized through the system's mechanized cleaning feature. Unlike static filter units that require frequent manual changing, the Prism's self-cleaning mechanism dislodges accumulated dust from the filter media, depositing it into a collection bin for easy disposal. This maintains optimal airflow and significantly reduces consumable costs over time. Furthermore, the inclusion of the K1669-4 Arc Sensor/Lamp Kit introduces intelligent automation to the workspace. The sensor detects the welding arc and automatically activates the fan, ensuring extraction is present exactly when needed while conserving energy during downtime.

Space-Saving Configuration

The wall-mounted configuration of the K4468-5 is engineered for facilities where floor space is at a premium. By elevating the filtration unit, valuable ground area remains clear for equipment and personnel. The included K1655-8 flexible extraction arm extends 10 feet, providing a wide operational radius that allows the welder to position the hood precisely over the weld pool without obstruction. This One-Pak® comes fully equipped with the base unit, arm, fan, sensors, and filters, providing a turnkey solution for industrial air quality compliance.
