K52009-1010 - MS250 Motorized Cross Slide System Kit 10x10

Precision Automation for Heavy Fabrication

The Lincoln Electric MS250 10 x 10 Motorized Slide System One-Pak© (K52009-1010) is a robust solution engineered for the rigorous demands of hard automation in welding. Designed to facilitate precise torch positioning, this system is integral for applications requiring consistent weld bead placement over long seams or complex geometries. The MS250 system is particularly effective for high-deposition processes such as Submerged Arc Welding (SAW), as well as Gas Metal Arc Welding (GMAW) and Flux-Cored Arc Welding (FCAW). By motorizing the vertical and horizontal axes, the system allows for real-time adjustments and fine-tuning that manual slides cannot match in continuous production environments.

Comprehensive One-Pak Configuration

Lincoln Electric’s One-Pak approach streamlines the integration process for industrial engineers and procurement specialists. This SKU bundles the core mechanical component—the CS250 Cross Slide with a 10-inch by 10-inch stroke—with the essential electronic control architecture. The package includes the K52025-1 MS Control Unit, which serves as the brain of the positioning system, and the K52024-1 MS Control Pendant, which provides the operator with an ergonomic interface for manipulating the slide. Also included is the K52030-1 Drive Cable Assembly, ensuring that all necessary connectivity between the drive motors and the control unit is present out of the box. Note that the system ships unassembled, allowing for flexible installation configurations suited to specific fixture designs.

Industrial Application and Integration

The MS250 system is built to withstand the harsh conditions found in heavy fabrication sectors, including shipbuilding, pressure vessel manufacturing, and pipe fabrication. The motorized slides enable the automation of repetitive tasks, significantly reducing operator fatigue and the potential for human error. The system's ability to handle the weight of heavy-duty torches and cable assemblies makes it a standard choice for retrofitting existing column and boom manipulators or custom-built welding gantries. Its compatibility with a broad range of Lincoln Electric power sources and feeders ensures it can be deployed as part of a holistic, high-performance welding cell.
