The Lincoln Electric Power Feed® 84 Single Boom Wire Feeder (SKU: K3328-1) represents the pinnacle of advanced process feeding technology. Designed for heavy-duty industrial applications, this semiautomatic wire feeder offers comprehensive process adjustability and control within a rugged, modular chassis. This specific model is supplied without a User Interface (U/I), making it the ideal choice for integrated boom systems, automated setups, or replacement scenarios where the control interface is located remotely or already present. By decoupling the interface, Lincoln Electric allows for greater flexibility in how the feeder is deployed within complex welding cells.
At the heart of the Power Feed 84 is a high-performance motor capable of delivering wire feed speeds ranging from 50 to 750 inches per minute (1.3-19 m/min). This wide range ensures compatibility with a vast array of welding processes, from low-speed precision work to high-deposition heavy fabrication. The unit operates on a 40 VDC input, ensuring consistent torque and speed regulation even under load. The digital control architecture supports Auto-Settings, which simplifies the setup process by automatically optimizing parameters based on the selected welding mode, reducing the potential for operator error.
Efficiency is maximized through the inclusion of eight separate user memories per feed head. This allows operators to store and instantly recall frequently used welding procedures, significantly reducing setup time between different tasks. A built-in USB port further enhances the unit's capabilities, enabling simplified machine setup, firmware updates, and the expansion of user profiles. This connectivity ensures that the Power Feed 84 remains a future-proof investment for modern fabrication shops.
Built to withstand the rigors of environments such as shipyards, construction sites, and heavy equipment manufacturing, the Power Feed 84 features improved isolation and environmental protection. Robust connection points ensure reliable operation in tough conditions, while the lightweight design (36 lbs) facilitates easier mounting on booms and fixtures. The unit includes a standard #2-#4 gun adapter, a 20-tooth pinion gear, and a conduit inlet bushing, providing the essential mechanical components for immediate integration.
| Additional Information |
|---|
| Brand:Lincoln Electric |
| Input Voltage:40 VDC |
| Warranty:5 Years |
| Weight:36 lb |
| Wire Feed Speed Range:50-750 IPM |
| Process Type:MIG, Flux-Cored |
| Input Power:40 VDC |
| Applications:Construction, Heavy Fabrication, Automotive, Shipbuilding |
| Packaging Description:1 Per Ea |
