K2536-5 - Lincoln Power Feed 25M Portable Wire Feeder, Plastic Case

Advanced Portable Wire Feeding Solution

The Lincoln Electric Power Feed® 25M Wire Feeder (K2536-5) represents the pinnacle of portable wire feeding technology, engineered specifically for demanding industrial environments such as shipbuilding, construction, and pipeline fabrication. Housed in a durable, flame-retardant plastic case, this unit is designed to withstand impact and harsh conditions while protecting sensitive internal components. The feeder utilizes Lincoln's proprietary ArcLink® digital communication protocol, ensuring lightning-fast data transfer between the feeder and compatible Power Wave® power sources. This digital link allows for precise control over welding parameters and enables features like Process Switching and remote waveform selection directly from the feeder.

One of the standout features of the Power Feed 25M is its optimized performance for aluminum welding. The unit comes standard with push-pull capability, allowing for uniform feeding of soft aluminum wires over long distances when paired with a push-pull gun. The MAXTRAC® wire drive system features a heavy-duty cast aluminum construction and a patented split wire guide design that significantly reduces birdnesting and ensures consistent electrical contact. For operators working in challenging field conditions, the 25M includes internal LED lighting to illuminate the drive rolls in dark spaces and an internal heating element that prevents moisture buildup on the welding wire, reducing the risk of hydrogen-induced cracking and porosity.

Operational efficiency is maximized through the Mode Select Panel (MSP4) and dedicated Dual Procedure/Memory buttons. Operators can store and instantly recall up to eight specific welding procedures, eliminating the need to memorize complex settings or return to the power source to make adjustments. The "Dual Procedure" function allows for on-the-fly switching between two distinct weld schedules—ideal for applications requiring different settings for root and fill passes. Weighing only 35 lbs and designed to fit through a standard 16-inch manhole, the Power Feed 25M brings advanced shop-floor capability to the most inaccessible job sites.
