The Esab Rogue ET 201iP PRO represents a significant leap forward in the entry-level professional welding category. Designed for the rigorous demands of industrial maintenance and fabrication, this inverter-based power source is housed in a molded fiberglass-reinforced case rated IP23S. This certification ensures the machine is protected against vertical water sprays and solid objects, making it suitable for use in tough outdoor environments where standard welders might fail.
Technically, the Rogue ET 201iP PRO excels with its comprehensive parameter control. It offers a true High Frequency (HF) start for non-contact ignition, eliminating tungsten contamination. The machine features Power Factor Correction (PFC), which allows for highly efficient operation on 115V or 230V networks and supports the use of extension cables up to 100 meters without voltage drop affecting arc stability. The TIG cycle is fully customizable, allowing operators to dial in gas pre-flow, start current, ramp-up, ramp-down, finish current, and post-flow.
A standout feature for precision fabrication is the Pulse TIG capability, adjustable from 0.2 Hz up to 500 Hz. This wide frequency range provides exceptional control over heat input, minimizing the heat-affected zone (HAZ) and reducing distortion on thin-gauge stainless steel. In SMAW (Stick) mode, the unit provides adjustable Hot Start and Arc Force, and introduces a unique Pulse SMAW feature to assist with vertical-up welding and spatter reduction.
| Additional Information |
|---|
| Brand:ESAB |
| Voltage:115/230 V |
| Weld Process:TIG (GTAW) |
| Amperage:200 |
| Packaging Description:1-per-ea |
| Process Type:TIG (GTAW), Stick (SMAW), Pulsed TIG |
| Input Voltage:115/230 VAC |
| Amperage Range:10-200 A |
| Duty Cycle:25% @ 200A |
| Portability:Handle, Shoulder Strap, Lightweight |
| Control Interface:Digital, Adjustable Parameters |
| Applications:Food & Beverage, Repair & Maintenance, Civil Construction, Agricultural Equipment, Industrial Fabrication |
| Protection Class:IP23S |
