The ESAB Thermal Dynamics Cutmaster 40 is designed for fabricators who need a machine that can travel anywhere without compromising on cut quality. Weighing in at just 10 kg (22 lbs), this unit boasts the highest power-to-weight ratio in its class. Whether you are working in a shop, on a construction site, or performing HVAC repairs, the Cutmaster 40's integral multi-handle design makes transport effortless.
Gone are the days of worrying about power input compatibility. The Cutmaster 40 features automatic voltage detection, seamlessly switching between 110V and 240V inputs. It automatically adjusts its maximum output to match the power source—delivering 27 Amps on 110V and the full 40 Amps on 200-240V. This flexibility allows you to plug in and cut virtually anywhere power is available.
Equipped with the legendary SL60 1Torch, this system offers a recommended cut capacity of 1/2 inch (12 mm) and can sever metals up to 1 inch (25 mm) thick. The torch features the ATC (Advanced Torch Connector) quick-disconnect system, allowing for tool-free swaps and easy storage. Included in the box are the new Cutmaster Black Series electrodes, engineered to last up to 60% longer than standard consumables, keeping you cutting longer and spending less on parts.
Durability is at the core of the Cutmaster design. The unit is IP23 rated, ensuring it can withstand harsh weather and industrial environments. Backed by ESAB's industry-leading 4-year warranty on the power supply and a 1-year warranty on the torch, you can invest with confidence knowing your equipment is protected by the Iron Clad Pledge.
| Additional Information |
|---|
| Brand:ESAB |
| Amperage:40 |
| Voltage:110/240 V |
| Weld Process:Plasma Cutting |
| Duty Cycle:40% |
| Packaging Description:1 of each |
| Process Type:Plasma Cutting |
| Input Voltage:110 V, 240 V |
| Output Amperage Range:15 - 40 A |
| Recommended Cut Capacity:1/2 inch (12 mm) |
| Maximum Severance:1 inch (25 mm) |
| Gas Requirements:Compressed Air |
| Gas Pressure:90-125 psi (6.2-8.6 bar) |
| Gas Flow:300-500 cfh (142-235 l/min) |
| Torch Model:SL60 1Torch |
| Torch Cable Length:16 ft (4.9 m) |
| Weight:10 kg (22 lbs) |
| Dimensions:18.1 x 7.9 x 12.6 inches |
| Warranty:4 Years Power Supply, 1 Year Torch |
| Cutting Capacity:5/8 |
