The Miller Big Blue 800 Duo Pro (Deutz) is engineered for the most demanding industrial environments, offering a robust combination of high-amperage welding output and substantial auxiliary power generation. At its core lies the heavy-duty Deutz TD2.9 L4 T4F industrial diesel engine, a 65.7 HP liquid-cooled turbo-charged power plant. This engine is EPA Tier 4 Final compliant, utilizing Diesel Oxidation Catalyst (DOC) technology to ensure clean operation without the need for Diesel Exhaust Fluid (DEF) or Diesel Particulate Filter (DPF) maintenance, ensuring maximum uptime and reduced operating costs.
This machine is designed to maximize fleet efficiency. The "Duo Pro" configuration allows for two independent welding arcs of up to 400 amps each, effectively functioning as two welders in one chassis. A simple paralleling switch on the front panel instantly converts the machine into a single-operator powerhouse delivering up to 800 amps. This versatility makes it ideal for heavy pipe fabrication, structural steel, and mining maintenance where requirements fluctuate between multi-operator light duty and single-operator heavy gouging or sub-arc applications.
The 907751 model comes standard with Miller's ArcReach technology. This system allows the power source to communicate with compatible wire feeders and remotes through the welding leads themselves. This eliminates the need for fragile and expensive control cables, which are prone to damage on job sites. Operators can adjust voltage and amperage at the point of the weld, significantly improving weld quality and safety by reducing the need to traverse hazardous job sites to make adjustments at the machine.
Beyond welding, the Big Blue 800 Duo Pro is a formidable generator. It provides 27,000 watts of peak 3-phase power (20,000 watts continuous) and up to 15,000 watts of peak single-phase power. This capacity is sufficient to run industrial tools, lighting towers, and job site trailers simultaneously. Built for harsh conditions, the unit features a heavy-duty powder coat with zinc-rich primer, a standard vandalism lockout kit, and thermal overload protection.
| Additional Information |
|---|
| Brand:Miller |
| Amperage:800 |
| Weld Process:Engine Drive, Multi-Process, Submerged Arc (SAW) |
| Watts:12000 W |
| Engine Brand:Deutz |
| Fuel Type:Diesel |
| Horsepower:65.7 hp |
| Generator Output (3 Phase Peak):27,000 W |
| Generator Output (1 Phase Continuous):12,000 W |
| Weld Output Mode:Single Operator (800A), Dual Operator (400A each) |
| Cooling:Liquid Cooled |
| Packaging Description:1 PER EA |
| Voltage:n/a |
| Duty Cycle:N/A |
