The Miller Trailblazer 330 Diesel Welder/Generator (907849003) is engineered for professional welders and fleet managers who demand versatility, efficiency, and reliability. Powered by a robust 24.8 HP Kubota D902 diesel engine, this machine delivers a massive 330 amps of welding output at 100% duty cycle, ensuring it can handle the most rigorous structural steel, pipe, and fabrication jobs without overheating or requiring downtime. What sets this specific model apart is the integration of Miller's exclusive Excel Power and Battery Charge/Crank Assist technologies, transforming it from a simple welder into a comprehensive mobile power station.
Efficiency is at the core of the Trailblazer 330. The exclusive Excel Power feature provides 2,400 watts (20 A) of pure 120-volt sine-wave power while the engine is at idle. Unlike competitive machines that must rev up to 3,600 RPM to provide auxiliary power, the Trailblazer 330 allows operators to run grinders, lights, and drills at fuel-saving, quieter idle speeds. Complemented by Auto-Speed technology, the engine automatically adjusts its speed to match the specific weld and load demands. This results in significantly reduced fuel consumption, extended engine life, and a quieter jobsite environment, enhancing safety and communication for the entire crew.
Miller has equipped the Trailblazer 330 with industry-leading arc technologies. Dynamic DIG works on a time-based algorithm to automatically adjust the amount of current required to clear a short, providing a smoother, more consistent Stick arc tailored to the application. For TIG welders, QuietPulse technology activates during DC pulse welding to create a slower, more fluid transition between background and peak amperage, drastically reducing audible noise. Furthermore, standard ArcReach technology allows the power source to communicate with remote wire feeders and stick/TIG remotes through the weld cables themselves, eliminating the need for fragile control cords and saving operators time by allowing parameter adjustments directly at the weld joint.
This model is specifically designed for mechanics and fleet operations. The integrated Battery Charge/Crank Assist system eliminates the need for separate charging equipment. Capable of charging 12V and 24V batteries at up to 150 amps and providing up to 300 amps of jump-start power, the Trailblazer 330 ensures that dead batteries on trucks, excavators, or other heavy equipment never halt production. This dual-purpose functionality maximizes the utility of the machine, making it an indispensable asset for mobile repair and maintenance teams.
| Additional Information |
|---|
| Brand:Miller |
| Weld Process:Engine Drive |
| Amperage:330 |
| Watts:12000 W |
| Duty Cycle:100% |
| Packaging Description:1 Per Ea |
| Engine Brand:Kubota |
| Fuel Type:Diesel |
| Horsepower:24.8 hp |
| Auxiliary Power:12,000 W Peak, 10,500 W Continuous |
| Process Type:MIG, TIG, Stick, Flux Cored, Air Carbon Arc Cutting |
| Portability:Lift Eye (Standard) |
| Sound Rating:74.7 dB @ idle |
