The Miller XR-AlumaFeed Suitcase Wire Feeder (301567) is a heavy-duty, industrial-grade solution designed specifically to address the challenges of feeding soft aluminum wire. Engineered for use with Miller's AlumaPower 350 MPa and 450 MPa power sources, this feeder utilizes advanced push-pull technology to deliver consistent, trouble-free feeding over long distances. By synchronizing the motor in the feeder with the motor in the XR-Aluma-Pro or XR-Pistol grip guns, the system eliminates the friction and buckling often associated with pushing soft aluminum wire through a liner, effectively preventing "bird-nesting" and downtime.
One of the standout features of the XR-AlumaFeed is its synergic capability. When connected to a compatible AlumaPower MPa power source, the feeder enables single-knob control over voltage and wire feed speed. As the operator adjusts the wire speed, the system automatically adjusts the voltage to maintain the optimal arc length. This reduces setup time significantly and ensures high-quality welds even for operators with varying skill levels. The unit also features a bright, easy-to-read digital display that provides real-time feedback on voltage, wire feed speed, and amperage, along with indicators for start/crater settings and advanced trigger functions.
Built for the harshest environments, the XR-AlumaFeed is housed in a totally enclosed, impact-resistant, and flame-retardant polypropylene case. This "Suitcase" design protects the internal wire, drive rolls, and electronics from dirt, moisture, and metal shavings common in shipyards and manufacturing plants. Despite its robust protection, the unit remains ultra-portable, weighing only 31 pounds, allowing welders to carry the feeder into tight spaces, manholes, or up scaffolding where traditional bench feeders cannot reach.
The feeder is packed with productivity-enhancing features. The Trigger Schedule Select (SCHD) allows operators to switch between two pre-set welding schedules simply by tapping the gun trigger, ideal for applications requiring different parameters for tacking and welding. Additionally, the integrated gas flowmeter ensures precise shielding gas delivery right at the feeder, eliminating the need to walk back to the cylinder to adjust flow rates. With gun calibration capabilities and adjustable run-in speeds, the XR-AlumaFeed offers total control over the aluminum welding arc.
| Additional Information |
|---|
| Brand:Miller |
| Weld Process:Wire Feeder |
| Weight:31 lb |
| Packaging Description:1 Per Ea |
| Input Power:24 VAC, 50/60 Hz |
| Wire Feed Speed:50 - 900 IPM |
| Wire Diameter Capacity (Aluminum):0.035" - 1/16" |
| Wire Diameter Capacity (Solid):0.035" - 0.045" |
| Dimensions:9 in W x 15.5 in H x 21 in L |
| Compatible Power Sources:AlumaPower 350 MPa, AlumaPower 450 MPa, XMT 350/450, Invision 352/450 MPa |
